Stainless Steel Metal Keypad for Self-Service Payment Terminals, Securities Inquiry Kiosks & Access Control Systems

Item No:CT-KPS18-16TM

  • Ideal for self-service payment terminals in public service areas
  • Perfectly suited for securities self-service inquiry kiosks in financial institutions
  • A reliable choice for access control systems in residential and commercial buildings
  • phone：86-574-62385056
  • Email：sales@chenttech.com

Product Description
Send Email To US

Product Show
  • Quick Details:
    1. 16 Keys Vandal proof IP65 stainless steel, Dot matrix keypad.
    2. carbon-on-gold key switch technology.
    3. Front mounting or rear moumting is available.
    4.symbol and letters on keys can be designed according to customer’s requirements.
    Descriptions:
    1. 16 Keys IP65 dynamic compact format vandal proof , stainless steel  Industrial numeric keypad with industrial PCB electronics.
    2. Industrial PCB with carbon-on-gold key switch technology with long stroke (2.0mm) with extremely good tactile feeling for fast and accurate data input without any noise.
    3. Ease of installation and maintenance.
    4.letter and symbol can be customized according to customer’s requirements.
    Special Features:
    1. Imposing stainless steel design, specially designed keypad meet the highest demands with regard to design, functionality
    longevity and high protection level.
    2. This keypad with willful destruction, vandal-proof, against corrosion, weather-proof especially under
    extreme climatic conditions, water proof/dirt proof, operation under hostile environments.
    Applications:
    A: unsupervised or semi -supervised positions of varied access control systems,security system, household applications.
    B:Industry application.
    C: shopping malls, hotels, airports, railway stations and other public areas,
    D:  Inquiry self-service terminal ,Ticket vending machines, renting,gas stations, Internet public telephone ,
    Industrial automation,access control,food industry,chemical industry,info points,multimedia kiosk,military equipments,payment system,video telephone etc.

  • Specifications:

    MECHANICAL DATA

    keys

    16 keys

    Switching material

    carbon-on-Gold key switch technology PCB

    Actuation Force

    0.6 N+/-0.1N (pressure point)

    Frame/keys materials

    Superloy

    Dimensions

    55.0mm * 55.0mm (L x W )

    G.W.

    180g approx

    Key top style

    Protuberant rectangular keys, laser engraved & etched legends on keys are available

    Key Size

    9.0mm x 9.0mm

    Life span

    more than 2000,000 cycles


    ENVIRONMENTAL ADAPTABILITY

    Operating temperature

    -20℃ to +75℃

    Storage temperature

    -35℃ to +85℃

    Operating RH

    30-90%RH

    Atmospheric pressure

    60-106Kpa


    RELIABILITY

    Protection Level

    IP65(front panel)

    Vandal resistant

    IK09
